GNEE Skid-Mounted PSA Oxygen Generator with Continuous Oxygen Supply and Intelligent Operation for Industrial Use

Gambar besar : GNEE Skid-Mounted PSA Oxygen Generator with Continuous Oxygen Supply and Intelligent Operation for Industrial Use

Detail produk:

Tempat asal:	CINA
Nama merek:	GNEE
Sertifikasi:	SGS

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	≥1set
Kemasan rincian:	Kemasan Kotak Kayu
Syarat-syarat pembayaran:	MoneyGram, Western Union, T/T, D/P, D/A, L/C.
Menyediakan kemampuan:	25 setiap bulan

Kontak

GNEE Skid-Mounted PSA Oxygen Generator with Continuous Oxygen Supply and Intelligent Operation for Industrial Use

Deskripsi

Bentuk proses:	Adsorpsi ayunan tekanan （PSA）	Operasi daya:	1 kw
Tekanan:	5-6 batang	Kapasitas:	3 Nm3/jam
dimensi:	245x181x365(mm)	Tekanan oksigen:	0,5Mpa- 15Mpa
Fitur:	Kemurnian tinggi	Aplikasi:	Medis, Industri, Budidaya Perairan, Pengolahan Air Limbah, Pembangkitan Ozon, dll.
Rentang hidup:	8-10 tahun	Tingkat produksi:	3-200Nm³/jam
Menyoroti:	Skid-Mounted PSA Oxygen Generator , Continuous Oxygen Supply Oxygen Gas Generator , Intelligent Operation Oxygen Generation Plant

GNEE On Site Oxygen Generator Manufacturers PSA Oxygen Gas Generator

The PSA oxygen generator is an intelligent on-site oxygen generator that utilizes pressure swing adsorption technology to produce high-quality oxygen with stable purity continuously. This series of pressure swing adsorption oxygen generators adopts a new product design concept and advanced oxygen production technology, featuring a skid-mounted design suitable for on-site oxygen supply of various purity levels.

Product Parameters

Air compressor	Air storage tank	Air Dryer	Oxygen buffer tank	Oxygen storage tank	External dimensions(m)	Total weight	Power KW
GAS-7.5P	CG1.2	GL-10AT	OT-0.2	OG20	6.1×1.5×2.4	1600	5.5
GAS-7.5P	CG1.2	GL-10AT	OT-0.2	OG20	6.1×1.5×2.4	1800	5.5
GA5-7.5P	CG2.4	GL-10AT	OT-0.6	OG20	6.2×1.5×2.4	2100	5.5
GA7-7.5P	CG2.4	GL-20AT	OT-0.6	OG30	6.3×1.7×26	2300	7.7
GA7-7.5P	CG2.4	GL-20AT	OT-0.6	OG30	6.4×1.7×2.6	2500	7.7
GA11-7.5P	CG3.6	GL-20AT	OT-1.1	OG50	6.5×1.7×3.2	3000	11.7
GA11-7.5P	CG4	GL-30AT	OT-1.1	OG50	6.7×1.7×3.2	3500	11.9
GA11+-7.5P	CG4	GL-30AT	OT-1.1	OG50	6.7×1.7×3.2	3700	11.9
GA15-7.5P	CG5.5	GL-30AT	OT-1.1	OG50	10.5×1.75×3.2	3800	16
GA15-7.5P	CG5.5	GL-40AT	OT-1.7	OG50	10.5×1.75×3.2	3850	16
GA15-7.5P	CG5.5	GL-40AT	OT-1.7	OG50	10.5×1.75×3.2	3900	16
GA1S-7.5P	CG5.5	GL-40AT	OT-1.7	QGF0	10.5×1.75×3.2	3950	16.5
GA18-7.5P	CG6	GL-60AT	OT-2.1	CG50	11×1.75×3.2	4000	20
GA18+-7.5P	CG6	GL-60AT	OT-2.1	0G50	11×1.75×3.2	4100	20
GA22-7.5P	CG6	GL-60AT	OT-2.1	OG50	11×1.75×3.2	4150	23.5
GA22-7.5P	CG8	GL-60AT	OT-2.6	OG50	11.5×1.75×3.2	4200	23.5
GA22+-7.5P	CG8	GL-60AT	OT-2.6	OG50	11.5×1.75×3.2	4300	23.5
GA30-7.5P	CG10	GL-60AT	OT-2.6	OG50	12×1.75×3.2	4500	31.5
GA30-7.5P	CG10	GL-80AT	OT-3	OG50	11.5×1.75×3.2	4600	31.5
GA30-7.5P	CG10	GL-80AT	OT-3	OG50	11.5×1.75×3.2	4650	31.5
GA30+-7.5P	CG12	GL-80AT	OT-3	OG50	11.5×1.75×3.2	4900	31.5
GA30+-7.5P	CG12	GL-80AT	OT-3	OG50	12.5x1.75x3.2	5000	31.5
GA30+-7.5P	CG12	GL-80AT	OT-3.6	OG60	12.8x1.75x3.25	5200	31.5
GA30+-7.5P	CG15	GL-100AT	OT-3.6	OG60	12.9x1.75x3.25	5300	32.5
GA30+-7.5P	CG15	GL-100AT	OT-3.6	OG60	12.9x1.75x3.25	5350	32.5
GA30+-7.5P	CG15	GL-100AT	OT-4	OG60	13x1.75x3.25	5400	32.5
GA37-7.5P	CG15	GL-100AT	OT-4	OG60	13.8x1.75x3.25	5450	39.5
GA37-7.5P	CG15	GL-100AT	OT-4	OG60	13.8x1.75x3.25	5500	39.5
GA37-7.5P	CG15	GL-120AT	OT-4.5	OG60	13.85.x19x3.25	5550	39.7
GA37+-7.5P	CG15	GL-120AT	OT-4.5	OG60	14.5x1.9x3.25	5800	39.7
GA37+-7.5P	CG15	GL-120AT	OT-4.5	OG60	14.5x1.9x3.25	5850	39.7
GA37+-7.5P	CG15	GL-120AT	OT-4.8	OG60	14.5x1.9x3.25	5800	39.7
GA45-7.5P	CG18	GL-120AT	OT-4.8	OG60	15x1.9x3.25	5950	47.7
GA45-7.5P	CG18	GL-120AT	OT-5	0060	15x1.9x3.25	6000	47.7
GA45-7.5P	CG18	GL-120AT	OT-5	OG60	15x1.9x3.25	6050	47.7

How PSA Oxygen Generators Work

Composition of Air

Before understanding PSA technology, it's important to know the composition of air we breathe:

78% nitrogen
21% oxygen
1% argon, carbon dioxide, and trace gases

Since nitrogen and oxygen make up the vast majority of air, PSA technology focuses on separating these two gases to provide high-purity oxygen.

The Principle of Adsorption

The heart of a PSA oxygen generator lies in the process of adsorption. PSA oxygen generators use a material called zeolite as the molecular sieve. Zeolite has a microporous structure that allows it to selectively adsorb nitrogen molecules while allowing oxygen to pass through.

The PSA Cycle

A PSA oxygen generator operates in a cyclic manner, alternating between high and low pressure to achieve oxygen separation:

Compression of Air: Ambient air is compressed and filtered to remove impurities
Adsorption Phase: Zeolite selectively adsorbs nitrogen while oxygen passes through (90-95% pure)
Desorption Phase: Pressure is reduced to release nitrogen and regenerate the tower
Switching Between Towers: Two towers work in tandem for continuous oxygen supply

Advantages

Low production cost
Simple process with fewer equipment components
High automation and operation convenience
Quick starting (30 minutes to full operation)
Can be operated intermittently
Low working pressure for safe operation
Good flexibility in adjusting oxygen purity and output

Packing & Delivery

Our PSA oxygen generators are packed with:

Wooden case with anti-collision foam blocks
Machines packed with stretch film and pearl cotton
Export standard packing
Two sets per 20ft or 40ft container
Boosters and fittings packed in separate wooden cases
Exterior signs and anti-collision protection
Special protection for fragile components (gauges, flowmeters, controllers)

In addition to PSA Oxygen Generators, we also produce VPSA Oxygen Generators, storage tanks, heat exchangers and other products. If you are interested in VPSA Oxygen Systems or other products, please contact us at info@gneeheatex.com.
