93%±2% Purity 600m2 VPSA Oxygen Generator with 0.5-1.5 kW/Nm3 Power Consumption for Industrial Use

93%±2% Purity 600m2 VPSA Oxygen Generator with 0.5-1.5 kW/Nm3 Power Consumption for Industrial Use
93%±2% Purity 600m2 VPSA Oxygen Generator with 0.5-1.5 kW/Nm3 Power Consumption for Industrial Use 93%±2% Purity 600m2 VPSA Oxygen Generator with 0.5-1.5 kW/Nm3 Power Consumption for Industrial Use 93%±2% Purity 600m2 VPSA Oxygen Generator with 0.5-1.5 kW/Nm3 Power Consumption for Industrial Use 93%±2% Purity 600m2 VPSA Oxygen Generator with 0.5-1.5 kW/Nm3 Power Consumption for Industrial Use

Gambar besar :  93%±2% Purity 600m2 VPSA Oxygen Generator with 0.5-1.5 kW/Nm3 Power Consumption for Industrial Use

Detail produk:
Tempat asal: CINA
Nama merek: GNEE
Sertifikasi: SGS
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: ≥1set
Harga: According to the product
Kemasan rincian: Requst/kustomisasi pelanggan
Syarat-syarat pembayaran: MoneyGram, Western Union, D/P, T/T, D/A, L/C.
Kontak

93%±2% Purity 600m2 VPSA Oxygen Generator with 0.5-1.5 kW/Nm3 Power Consumption for Industrial Use

Deskripsi
Laporan Uji Mesin: Asalkan Bahan kapal luar: Baja karbon
Titik embun: -65 ℃ Diameter kapal luar: 2000 mm
Output nitrogen: ≤250Nm3/jam Tingkat produksi: 100 ~ 10000nm3/H.
Konsumsi Daya: 0,5-1,5 kW/Nm3 Kekuatan kompresor udara: 22-110KW
Catu daya: 380V/50Hz Rentang Hidup: +10 tahun
Output oksigen: ≤500Nm3 / jam Penggunaan: Oksigen
Materi dalam: Baja Tahan Karat Tekanan tes: 0.8MPA-1.6MPA
Menyoroti:

93%±2% Purity VPSA Oxygen Generator

,

600m2 VPSA Oxygen Generator

,

0.5-1.5 kW/Nm3 Power Consumption Oxygen Generator

93%±2% 600m² VPSA/VSA Oxygen Generator for Float Glass
VPSA/VSA series oxygen production equipment uses molecular sieve to selectively adsorb oxygen in the air at room temperature. By reducing the pressure of the adsorption tower to desorb oxygen from the molecular sieve, it achieves continuous oxygen production with purity of 90-95%. This energy-efficient solution is widely used in glassware polishing and glass kiln combustion support, proven to reduce energy consumption by 30-60% in glass industry applications.
VPSA Oxygen Equipment Technical Parameters
Model O₂ Flow (Nm³/h) O₂ Purity (±2%) O₂ Pressure (MPa) Air Consumption (Nm³/h) Adsorption Form
VPSA-3 3 93% 0.2 0.6 Normal Pressure Adsorption
VPSA-6 6 93% 0.2 1.2 Normal Pressure Adsorption
VPSA-10 10 93% 0.2 2 Normal Pressure Adsorption
VPSA-20 20 93% 0.2 4 Normal Pressure Adsorption
VPSA-30 30 93% 0.2 6 Vacuum Adsorption
VPSA-50 50 93% 0.2 10 Vacuum Adsorption
VPSA-80 80 93% 0.2 16 Vacuum Adsorption
VPSA-100 100 93% 0.2 20 Vacuum Adsorption
VPSA-150 150 93% 0.2 30 Vacuum Adsorption
VPSA-200 200 93% 0.2 40 Vacuum Adsorption
93%±2% Purity 600m2 VPSA Oxygen Generator with 0.5-1.5 kW/Nm3 Power Consumption for Industrial Use 0 93%±2% Purity 600m2 VPSA Oxygen Generator with 0.5-1.5 kW/Nm3 Power Consumption for Industrial Use 1 93%±2% Purity 600m2 VPSA Oxygen Generator with 0.5-1.5 kW/Nm3 Power Consumption for Industrial Use 2
Public Works Requirements (Customer Provided)
System Name Content Parameter
Vacuum pump sealing water Flow 3m³/Hr
Temperature <32ºC
Water quality (soft water) <30mg/L (CaO), suspended matter: 5mg/L, pH value: 6~9
Pressure >0.2Mpa sent to the water inlet of water equipment
Vacuum pump cooling water Flow 4m³/Hr
Temperature <32ºC
Water quality (soft water) <560mg/L (CaO), PH value: 6~9
Pressure >0.3Mpa sent to the water inlet of water equipment
Oxygen compressor cooling water Flow Air-cooled
Instrument air for butterfly valve Quality Dry, clean instrument air or inert gas
Flow 180m³/Hr
Dew point temperature -40ºC
Dust particle size Not more than 0.3μm
Pressure 0.4~0.7Mpa sent to the air bag (sub-cylinder)
Power requirements Voltage 380V
Installed capacity 539KW sent to the equipment receiving cabinet
Civil plant The project is designed outdoors without the client providing a factory building.
Equipment basis Construction according to drawing requirements
VPSA Oxygen Generator Advantages
  • Unique adsorption design prevents tank agitation for stable operation
  • Minimized invalid space increases operational efficiency
  • Low energy consumption with stable purity despite environmental changes
  • Advanced diagnostic program for fault identification
  • Fully automatic operation with low noise and valve wear
  • High reliability with rapid startup (20-30 minutes)
  • Fault-safety shutdown mode for protection
  • Low capital and maintenance costs with simple design
  • Extended valve service life through superior design
  • No cooler required, preventing molecular sieve wetting
In addition to VPSA Oxygen Generators, we also produce PSA Oxygen Generators, storage tanks, heat exchangers and other products. For inquiries about VPSA Oxygen Systems or other products, please contact us at info@gneeheatex.com. We look forward to serving you.
