Detail produk:
|
Inner Cylinder Material: | Q345R | Condition: | new |
---|---|---|---|
Outer Vessel Material: | Carbon Steel | Key Selling Points: | Long Service Life |
Keywords: | lng storage tank for sale | Geometric Volume: | 10.520m3 |
Fluid: | LNG, LOX, LIN, LAR, LCO2, etc. | Working Years Design: | 20years |
Menyoroti: | 40ft LPG storage tank,T50 cryogenic storage tank,LPG tank with warranty |
Attribute | Value |
---|---|
Inner Cylinder Material | Q345R |
Condition | New |
Outer Vessel Material | Carbon Steel |
Key Selling Points | Long Service Life |
Keywords | LNG storage tank for sale |
Geometric Volume | 10.520m³ |
Fluid | LNG, LOX, LIN, LAR, LCO₂, etc. |
Working Years Design | 20 years |
LPG gas storage tanks are professional products for storing LPG gas. LPG gas storage tanks are special equipment, Class III pressure vessels, and are made of 06Ni9DR materials. LPG gas storage tanks are manufactured through flaw detection, water pressure and air pressure tests, on-site inspections by the Technical Supervision Bureau, and pressure vessel inspection certificates are issued. External rust removal and painting are also required. Liquefied gas storage tanks have strict quality appraisals for the material of pressure components, appearance dimensions and weld quality, operation quality, installation quality, internal devices, and safety accessories.
Capacity of LPG Tank | 5m³ |
---|---|
Orientation of LPG Tank | Horizontal Single Layer LPG TANK |
Design Pressure | 1.77MPa |
Working Pressure | 1.63MPa |
Working Temperature | -19~50℃ |
Medium | LPG (Propane) |
Heat Treatment | Post-weld heat treatment for LPG Tank |
Design, Manufacturing and Inspection Standard | ISO/CE/ASME for LPG TANK |
Volume (m³) | Nominal Diameter (mm) | Thickness (mm) | Weight (kg) | External Dimensions Length × Width × Height (mm) | ||
---|---|---|---|---|---|---|
10 | 1600 | 10 | 10 | 3000 | 3990 | 5260×1620×2870 |
12 | 1800 | 10 | 10 | 3300 | 4788 | 5030×1820×3070 |
15 | 1800 | 10 | 10 | 3860 | 5985 | 6260×1820×3070 |
20 | 2200 | 12 | 12 | 5020 | 7980 | 5654×2224×3470 |
25 | 2200 | 12 | 12 | 6100 | 9975 | 7004×2224×3470 |
32 | 2400 | 14 | 14 | 7985 | 12768 | 7588×2428×3760 |
40 | 2700 | 14 | 16 | 9720 | 15960 | 7472×2728×3973 |
45 | 2700 | 14 | 16 | 10440 | 17955 | 8342×2728×3973 |
50 | 2200 | 12 | 14 | 6020 | 9975 | 7088×2224×2814 |
50 | 2300 | 12 | 14 | 7110 | 12768 | 8158×2324×2914 |
60 | 2400 | 14 | 14 | 7710 | 12768 | 7508×2428×3018 |
65 | 2300 | 12 | 14 | 8630 | 15960 | 10400×2324×2914 |
80 | 2400 | 14 | 14 | 9380 | 15960 | 9270×2428×3018 |
45 | 2700 | 14 | 16 | 10220 | 17965 | 8342×2728×3318 |
50 | 2600 | 14 | 16 | 11325 | 19950 | 9908×2628×3890 |
50 | 2700 | 14 | 16 | 11325 | 19950 | 9182×2728×3990 |
60 | 2700 | 14 | 16 | 13035 | 23940 | 10962×2728×3990 |
65 | 2700 | 14 | 16 | 13895 | 25935 | 11832×2728×3990 |
80 | 2800 | 16 | 16 | 17840 | 31920 | 13512×2832×4090 |
The following safety measures are recommended when working with LPG tanks:
GNEE's corporate culture emphasizes "achieving customers and making employees happy". We adhere to the values of "embracing changes and taking responsibility in actions; there is no best, only better", encouraging employees to constantly pursue excellence and make continuous progress. The company not only focuses on the technical development of the team, but also cares about the personal growth and happiness of employees, striving to create a healthy and harmonious working environment.
If you want to learn more about GNEE's products, you can send an email to info@gneeheatex.com. We are more than happy to assist you.
